Live Video Series For Collision Repair
This page is for students and instructors.
I know the coronavirus has canceled many schools, including the college where I teach. To help out, I am going to start providing live videos for your students, if you do not have other delivery methods prepared.
I know you all are on many different topics, I will not be able to cover every topic, but I will do the best I can per your request.
I am a Platinum I-CAR educator and Master ASE Certified Technician. I do not have all the answers yet, but I am going to help as much as I can. These videos will be ad-free videos without distraction.
I have been teaching collision repair since 2004, and I am here to help other instructors in any way I can. I will be providing additional resources as we move forward to ensure your students get the training needed for the remaining school year.
I will let you know more about the delivery method soon. In the meantime, let me know the topics you need to be covered.
Thanks, Donnie Smith
I will start a new video series for students soon. In the meantime, I have a short series that may be helpful for paint and refinish.
3/30 Monday – Restoration Block Sanding Tips With Hilary From Ink and Iron All Female Garage
Safety - Paint and Refinish
Part 1 - Surface Preparation
Part 2 - Strip paint to bare substrate (paint removal)
Part 3 - Dry or Wet Sand Areas to be Refinished
Part 4 - Featheredging
Part 5 - Metal Treatment
Part 6 - Masking
Part 7 - Mixing Primer
Part 8 - Selecting Correct Undercoating
Part 9 - Apply Primer To Repair Area
Part 10 - Block Sand Primer Surfacer
-
Safety - Paint and Refinish
This video covers some of the ASE task for the B2 Paint and Refinish – Part A Safety Precautions. For the resources mentioned in this video click the get more button. -
Part 1 - Surface Preparation
B.1 – B.3 Surface Preparation 1. Inspect, remove, store, and replace exterior trim and components necessary for proper surface preparation. 2. Soap and water wash entire vehicle; use appropriate cleaner to remove contaminants. 3. Inspect and identify substrate, type of finish, surface condition, and film thickness; develop and document a plan for refinishing using a total productsystem. -
Part 2 - Strip paint to bare substrate (paint removal)
-
Part 3 - Dry or Wet Sand Areas to be Refinished
B.5 Surface Preparation - Adhesion There are two types of adhesion, chemical adhesion and mechanical adhesion. Chemical adhesion may occur after a coating has been applied and another coating can be applied without sanding. For example, if epoxy primer has a 72 hour window, then primer surfacer or a top coat can be applied over the epoxy without sanding during this time period. Or if base coat has a 24 hour window. then the clear coat can be applied over the base coat without sanding. However, if the coating is not sprayed within the recommended window time period, the coating will lose its chemical adhesion. Therefore, you must provide a mechanical adhesion for the coating to properly adhere or stick. I just wanted to clarify the types of adhesion so there is no confusion between the two. In this task we are going to focus only on mechanical adhesion, which is produced by sanding. Final Sanding Whether you are prepping an old paint finish or primer surfacer, it must be final sanded to prepare is for primer sealer and paint. To do this you can use a wet sand method or a dry sanding method. Dry Sanding Most production shops have started using the dry sanding method using a DA sander and a soft interface pad. The interface pad helps provide less sanding marks and increases conformability, allowing the technician to follow contours and get in closer to most edges. Generally 400 grit to 600 grit sandpaper is used for final sanding to prepare the old paint surface for primer sealer and paint. However, waterborne paint may require up to 800 grit sandpaper for final sanding. Read your technical data sheet for the product you are using for their specific recommendations. A soft hand pad can also be used to dry sand the substrate by hand. However, hand sanding takes longer and requires more effort than using a DA sander. Wet Sanding Before the interface pad was introduced to the industry most shops preferred wet sanding and some shops still prefer this method. This is done by hand sanding or using a soft hand pad to final sand the surface. The grit recommendations are the same (400 to 600 grit), but wet sanding uses a sandpaper designed for wet sanding. This method does work well, but will take more effort and time than the dry sanding method using a DA sander. To use this method, water must be applied to the surface to help cut the substrate and to keep it clean. The best way I have found is to use a spray bottle and spray the surface often while sanding. A bucket with water and a sponge or a water hose with the water pressure set low will also work. However, if using a hose, it’s best not to have a metal end on the hose that can scratch the paint surface during the process. Final Sanding Regardless of the method used, the goal is the same. That is to provide a mechanical adhesion to the coating applied will adhere properly and not peel off. With this is mind, sand the substrate until the glossy surface has become dull from sanding. Check the surface often to make sure there are no glossy spots showing. If there are, this indicates that that spot was missed or not sanded good enough while sanding. These spots will need to be re-sanded. Edges Be sure to concentrate on the edges of the body parts. These are the spots commonly missed, but if paint is going to peel, it is more likely it will start peeling from an edge. Hard To Get Area Hard to get areas may be hard to get with a DA sander so these areas may need to be sanded by hand. One last step to assure these areas are sanded is to hand scuff them using a scotch-brite pad. Make sure the correct scuff pad is being used. 3M’s red scuff pad generally works well for areas that are going to painted. Their gray scuff pad works for most areas where clear coat only is going to be applied. There are other products that may be used to final scuff the substrate such as a final scuffing paste. -
Part 4 - Featheredging
ASE Task – Featheredge areas to be refinished. HP-I What Is Featheredge Featheredging is the process of layering each layer of coating making a level surface from the substrate to the top surface. It is kind of like stars compared to a ramp going to a building. The stair are steep and with a noticeable difference in height between each step. A ramp made for wheelchairs gradually goes from the ground to the top level with a much smoother transition. This is generally going to take a longer path to reduce the ramp being as steep as the stairs. Feathering paint is the same process. We need to take the hard paint edge and layer each coating at least ¼ inch to produce the smooth transition. So a small chip or scratch is going to be a big area when featheredged. Areas That Need Featheredged If you remove the coatings to perform bodywork you will need to featheredge the paint edges. Also if there are any scratches from sanding, or if the car was scratched during an accident or keyed, the area will need to be featheredged to level and provide that smooth transition from the substrate (bottom of scratch) to the top surface (clear coat). This may require several layers of coating to feather. For example, you may have e-coat, primer, basecoat, and clearcoat. Each coating should be layered ¼ inch. Another problem that may require featheredging are rock chips. Rock chips follow the same concept of providing a smooth transition from the top surface to the bottom of the rock chip. How To Featheredge Featheredging is performed using a DA sander. 220 grit is the most common sandpaper used for this. When using a DA sander, do not use the interface pad. Remember in the video over final sanding, the interface pad follows the contours of the surface. If the interface pad it following the contour of the paint edge, then it’s going to make it difficult to layer the coatings. So a harder surface is going to work better. Therefore, use the DA sander and sandpaper is all that is needed. Featheredging can also be performed block sanding the surface with 220 grit. This is going to take more effort and time, but t can be done. What Problems Can Improper Featheredging Cause If the surface was not feathered enough you risk seeing rings in the surface after the part has been painted. You may even see multiple rings where the different layers were feathered. To eliminate this be sure to sand each layer at least ¼ inch. It is also a good idea to primer and block sand any areas that were featheredged. By properly featheredging, priming, and blocking, the area will not be noticeable after the vehicle has been painted and clear coated. Example Questions Technician A says feather edging may be used to sand rock chips. Technician B says an interface pad should always be used while feather edging. Who is right? Technician A Technician B Both A and B Neither A or B 2. Technician A says 220 grit may be used for feather edging. Technician B says each coating should be feathered at least 1/4 inch. Who is right? Technician A Technician B Both A and B Neither A or B -
Part 5 - Metal Treatment
B:7 Apply suitable metal treatment or primer in accordance with total product HP-I systems. Every paint system is going to have their own recommendations when it comes to providing corrosion protection to bare metal. However, there are 4 basic methods that may be used. Metal Conditioner and Conversion Coating – This is an older method, but may still be used by some shops. The metal conditioner is a phosphoric acid that cleans and etches bare metal to improve adhesion before priming. Metal conditioner has acid and must be neutralized after applied. This product is generally mixed or diluted with water and sprayed onto the metal surface using a spray bottle. After this the metal conditioner is applied to the metal, water is then used to rinse the surface to neutralize the acid. Dry metal then apply the conversion coating. Conversion Coating is a zinc phosphate coating that chemically bonds to the metal. The conversion coating is applied with a spray bottle like the conditioner. The surface should not dry on its own so you may have to keep applying it to the surface for around 5 minutes. Then the metal needs to be rinsed with water and dried. Once dry, the metal forms a coating that provides corrosion protection and will have good adhesion for primer to adhere to. This method is more time consuming than the other methods. It was used more with the old lacquer primers. Advanced primers has made it possible to eliminate this method. Self Etch Primer Self etching primer has an acid that etches to bare metal. Self etch should be applied directly over bare metal. It is usually not recommended to use metal condition and conversion coatings is self etch primer is going to be used. Self etching primer provides good adhesion and corrosion protection. The primer comes in both a 1 part and 2 part systems. Epoxy Primer Epoxy is a primer designed to be sprayed directly over bare metal. Epoxy provides good adhesion and corrosion protection. Epoxy only comes in a 2 part system. Direct To Metal There are some direct to metal primers, which may be applied directly over bare metal. For instance, a direct to metal primer surfacer. This can be used on a surface that needs to be block sanded. Direct to metal primers eliminates the need for metal conditioner, conversion coatings, self etch primer, or epoxy primer. However, don’t assume that all primer surfacers may be applied directly over bare metal. If it is not a direct to metal, one of the other methods must be applied before applying the primer surfacer. It is best to use one product line (brand) and follow the recommended procedures found on the technical data sheet, as each paint line may vary. 1. Technician A says metal conditioner and conversion coating should always be applied before applying self etch or epoxy primer. Technician B says all primer surfacers are designed to be applied directly over bare metal. Who is right? Technician A Technician B Both A and B Neither A or B 2. Technician A says metal conditioner and conversion coating is the most common method used today for providing corrosion protection and adhesion. Technician B says the specific technical data sheet should be read for each product used. Who is right? Technician A Technician B Both A and B Neither A or B -
Part 6 - Masking
B8 – Mask and protect other areas that will not be refinished. HP-I Adjacent parts must be masked off to prevent primer or paint overspray from getting on them. This is done a number of ways, which we will discuss. JAMBS FIRST While I am discussing masking jambs, you also want to do your jambs first, as it may be difficult to open the door without ruining the masking job. JAMB MASKING TECHNIQUES There are several different methods to achieve this. One method is to mask 1/4 inch back from the jamb edge. You can use 3/4 inch tape and 3 inch masking paper. However, straight masking with this method will leave a hard edge from the paint. BACK MASKING This is a reverse mask technique that makes a softer edge. Basically, you simply fold the tape over and allow the tape to be slightly pulled, creating a soft edge that is less noticeable. APERTURE TAPE This may also be know as foam or rope tape. This is a foam that makes a seal between the two jamb areas. This method works extremely well and is a fairly simple and quick method. Aperture tape come in a variety of widths for different gap opening sizes. TRANSITION TAPE If you want an absolutely invisible repair, then consider using the transitional tape. This tape is amazing. It has adhesive in the middle of the tape, which creates smooth edge. May or may not be recommended by paint manufacturer, but you can literally apply this tape on a body line and not be able to see the clear coat line. Masking Before Priming – No Hard Edges One of the common mistakes is making hard edges with the primer. This is done by masking a square around the damaged area. During the priming process, primer is sprayed against the tape edge causing a hard edge. This creates additional work trying to feather the primer edge smooth. There have been times when the primer lines were sanded completely out when sanding, but were slightly visible after the paint job was complete. Save yourself time, energy and the possibility of this paint defect by not making this mistake. There are times when you want to keep the repair area small, such as a repair that is blend within a panel or close to an adjacent panel that is not going to be a blend panel. But there are a few thing you can do to keep the repair area small. Adjust your primer gun to spray a smaller area and blend the primer into the paint surface. This will produce the best result if you have room on the panel to do this. If you do not have enough space to blend you primer, then the back masking method can be used. This still is going to leave an edge, but it will be a smoother edge. Tips For Masking Windshields and Glass There are several ways to mask a windshield, which we will discuss. This is a critical area and has caused a lot of problems due to the molding setting close to the paint surface. One of the problem this causes is when the clearcoat is applied. Clear coat requires heavy mills and can bridge over from the painted surface to the tape edge. This means that the clear makes a complete seal filling in the gap. After the clear is dry and the masking tape is removed, this will make a sharp jagged edge. Even worse, if the tape does not pull off straight, it may take a chunk of clear coat off the painted surface, which will result in respraying the panel. Let’s start off discussing techniques to mask the glass. First, we want to avoid creases in the paper. Creases in the paper creates a place for dust and dry overspray to land. When the pressure from the spray gun hits it from the next coat, it may blow the dust out of the crease and into the paint job. This will require extra buffing, which is extra time spent on the job that could be eliminated. To create a creaseless masking job, do not bend the masking paper when masking. Easier said than done, but let me go through the steps with you. First, use ¾ masking tape to outline the glass molding. Then using 18 inch masking paper with ¾ inch tape to cover the remaining portion of the glass. It is best to tear of sheets off the masking paper to cover the entire length of the glass with one sheet to eliminate seams that will need to be masked. Now start by placing the masking tape on the masking paper to the center section of the masking tape that is already attached to the car. From the center, pull each side of the masking paper straight back making a straight line. This will probably not follow the molding, but that is alright. If you follow the molding, the paper will create creases, which is what we want to eliminate. Now that the paper is straight across the glass area, use a razor blade to cut the paper around the molding. Care must be taken not to cut the glass or molding. This can be done by holding the paper up while making the cut. Once the masking paper has been cut to fit, use ¾ inch tape to mask around the remaining edges. Now the paper should be masked completely around the glass to the tape that we used to outline the glass molding with. If you use this method you will have minimal creases in your masking paper. If you do have a crease, tape the crease solid using masking tape. If one layer does not completely cover the width of the glass use another piece of paper on the other end and repeat the process. Once all edges are completely taped, mask the seam of the two layers of masking paper. When completed, all edges, creases, and seams should be taped. This will complete a seal, which will eliminate overspray from entering the paper and getting on the glass or molding. This will also eliminate pockets and creases in the masking paper that can attract dry overspray and dust. This will provide a cleaner job and less dirt in the finished paint job. This will result in less sanding and buffing after the paint job is completed to remove dirt nibs. How To Avoid The Clear Coat From Bridging on Molding That Fit Close To or Touch The Painted Surface Being Sprayed Many times a molding fits tight against or even touches the painted surface. The problem with this is that the clear coat may fill in the gap or crack between the molding and paint surface. In other words, the clear coat bridges over from the painted surface to the masking tape. When the paint is dried and the masking tape is removed, the clear coat will have a rough edge from the clear coat. Even worse, it may even pull a chunk of clear coat from the painted surface. If this happens, the surface may have to be sanded, re-painted, and cleared. There are several ways to avoid this. If the glass molding is soft and flexible enough a small diameter rope can be used to shove under the molding. This will lift the edge of the molding up, which will allow the paint coating to flow underneath the molding. Once the paint is dry, remove the rope, which will allow the molding edge to sit back on top of the newly painted surface. There is also a special masking product, which has a hard plastic edge on one end and adhesive tape on the other end. First place the hard plastic edge underneath the edge of molding. Then fold the adhesive side over and stick to the glass. This will lift the edge of the molding up, which will allow paint coatings to flow underneath the moding. When the trim mask is removed, the edge of the molding will set back on top of the newly painted surface. Sometimes the molding is too rigid and the molding is difficult to lift. In these cases, there is another method that can be used. When outline the molding with ¾ inch masking tape, leave about ⅛ inch of the molding exposed. Then mask the glass as you normally would using masking paper. Once completely masked, use ¼ inch fine line tape to go around the edge of the molding. This tape will cover the the molding edge and the masking tape that was used to outline the molding. It is important to apply the i/4 inch tape last so it will be easy to pull off. Immediately after applying the last coat of clear coat, pull the ¼ inch tape from the molding. Care needs to be taken not to let the tape hit the fresh clear coat finish. This will produce a smooth transition instead of creating a hard edge if removed after the clear has dries. This will also eliminate the risk of pulling a chunk of clear from the painted surface. A Tip For Masking Hose Lines and Wiring Another problem you may run into when masking is masking off hoses and wiring. I have seen them wrapped in masking tape, but the problem is unmasking. This can be a tedious time consuming job. However, there is a quick fix for these parts. Use aluminum foil to wrap around these parts. The foil will form around the part to protect the part from paint. The cool thing is that the foil is as easy to remove as it is to put on. This works great for parts such as: fuel lines, door wiring harness, inside door parts when paint the inside of a door, inside door handle, etc. Tips For Covering Holes To mask holes such as tail light access holes, windshield wiper holes, door handle access holes, place masking tape to the back side of the hole to seal the hole shut. Let’s say you have the car masked off and you realize a small windshield washer hole is not masked off. Before you start opening your door and hood ruining the masking job, try this little trick. If it is a small hole, use a foam earplug. You can squeeze the ear plug making it small to fit inside the hole, then as it expands, it will seal the hole shut. Of course, this will not work for large holes, but the larger holes are as often overlooked when masking. It’s the small holes that is often forgotten about until the car is already masked off. Well, that should not be a problem now! -
Part 7 - Mixing Primer
B9: Mix primer, primer-surfacer or primer-sealer. HP-I -
Part 8 - Selecting Correct Undercoating
B.10 Surface Preparation – Identify a complimentary color or shade of undercoat to improve coverage. Before we discuss undercoat, let’s talk about paint. Paint consists of three things; pigments, which is the color, solvents to make the pigments a liquid form...to read full text click the view more button. -
Part 9 - Apply Primer To Repair Area
B:11 Apply primer onto surface of repaired area. HP-I Primer surfacer is designed to be applied over the repair area. Anytime body repair was performed, primer surfacer needs to be applied to fill small imperfections. Keep in mind that if you have any bare metal you may need to apply epoxy, self etching primer or a direct to metal primer surfacer to provide corrosion protection. Once the body repair has been completed, it’s been feather edged, cleaned, and the metal treated for corrosion protection, then apply the recommended coats of primer surfacer. It is not necessary to apply primer surfacer over the entire panel. Only the repair area will need primed. Read the technical data sheet for the specific primer you are using as the recommendations vary with different paint manufactures. The technical data sheet will say how many coats, how long the primer needs to flash between coats, how long the primer needs to dry before sanding, what size of gun to use, and more. Many problems can occur from applying too much primer at one time and not waiting the flash times between coats. Another thing to keep in mind is that primer surfacer must be sanded, which is another good reason not to apply primer surfacer over the entire panel. This will require more effort and time due to sanding and waste more primer. Once the recommended coats of primer surfacer have been applied, wait the recommended dry time, then it will be ready to block sand. -
Part 10 - Block Sand Primer Surfacer
ASE Task Paint and Refinish Prep 7: 14. Block sand area to which primer-surfacer has been applied. HP-I 15. Dry sand area to which finishing filler has been applied. HP-I 58 1/1/2018 16. Remove dust from area to be refinished, including cracks or moldings of adjacent areas. HP-I 17. Clean area to be refinished using a final cleaning solution. HP-I 18. Remove, with a tack rag, any dust or lint particles from the area to be refinished. HP-I
